产品特点
1.高放大倍率 2.可接三脚架,外接辅助光源灯,手柄
3.先进的光学系统 4.高分辨率
5.精致耐用的材质 6.内置红外辅助照明器
7.可靠易操作性强 8.2年保修期,终生维护
产品参数
参数
|
指标
|
增强管
|
二代加
|
镜头
|
第三代光学镜头
|
分辨率
|
45-53lp/mm
|
物镜倍率Lens magnification,x
|
5
|
物镜系统Lens systems
|
80mmF/1.7
|
视场Field of view,deg
|
12.5
|
调焦范围Focus range,m
|
1.5 to infinity
|
物镜直径Objective lens diameter,mm
|
50
|
重量Weight,g
|
680
|
尺寸Overall dimensions,mm
|
182X100x65
|
观察距离Detecyion range,m
|
500
|
瞳孔直径Exit pupil duaneter,mm
|
6
|
屈光度Eyepiece Duioer adjustment,dptr
|
+4/-4
|
瞳孔距离Eye relief,mm
|
15
|
电池寿命(开IR)Battery life IR on,hour
|
Up to 20小时
|
电池寿命(关IR)Battery life IR on,hour
|
Up to 60小时
|
IR功率IR Power,mw
|
25≤
|
IR波长IR wavelength,nm
|
850
|
防水标准IP standard of water-resistence
|
IPX4
|
湿度Humidity,%
|
93
|
操作温度Operating temperature,℃
|
-40°to+50°
|
储藏温度Storage temperature,℃
|
0°to+50°
|
|
|
